ไฮไลท์
จำหน่าย นำเข้า ขาย ตัวแทนจำหน่าย เบรคลม NIIKA DBG DBG104 DBG105 DBG - Caliper Disc Brake(Air-operated, Manual)
ข้อมูล
น้ำหนัก
บาร์โค้ด
ลงสินค้า
อัพเดทล่าสุด
รายละเอียดสินค้า




DBG - Caliper Disc Brake(Air-operated, Manual)
Zoom

DBG - Caliper Disc Brake(Air-operated, Manual)



1. Adjustable braking force : The braking force can be adjusted by adjusting the air pressure, making it suitable for a wide range of applications.
2. Space-saving : The vertical type installation saves space and is easy to maintain.
3. Waterproof, dust-proof, and heat-resistant : The brake is waterproof, dust-proof, and heat-resistant, making it suitable for harsh environments.
4. Safe : The brake uses air pressure or manual operation as the power source, which eliminates electric sparks and makes it explosion-proof.
5. Long-term braking : The manual brake can maintain effective braking for a long time in the absence of air pressure by manually operating and compressing the springs.
6. Applications : packing and printing machinery, rubber tire machinery, wire machinery, paper making machinery, stretch-wire machinery, stranding machinery, trimming shears machinery, winding/unwinding machinery, orientation machinery, tension controller, etc.

Description
The friction part is easy to replace, and it does not contain any asbestos,
To control the deceleration of moving parts for small
and medium powers, the best solution is the combination of
a brake disc with one or more pneumatic calipers.

Torque Formula :
Braking Torque (kgm) =Braking Force (kg) x Effective Disc Radius (Actual)(mm)
Size DBG 104 DBG 105
Maximum under overload 7 kg/cm² 7 kg/cm²
Compression ratio 0.74 0.74
Disc thickness 10 mm 10 mm
Disc O. D. mm 20↑ 20↑
Unit Weight 5.5 kg 6 kg
Torque versus Pressure
Size X Y φZ
DBG 104 18 145 142
DBG 105 36 160 177
